| Frame Rated Current Inm (A) | 1600 | 2000 | 2500 | 3200 | 4000 | 6300 |
| Rated Working Voltage Ue (V) | AC 380/400/415V, AC 660/690V |
| Rated Working Current In (A) | 200/315/400/500/630/800/1000/1250/1600 | 400/500/630/800/1000/1250/1600/2000 | 400/630/800/1000/1250/1600/2000/2500 | 2000/2500/2900/3200 | 3200/3600/4000 | 4000/5000/6300 |
| Rated Frequency (Hz) | 50/60 |
| Rated Insulation Voltage Ui (V) | 1000 |
| Rated Impulse Withstand Voltage Uimp (kV) | 12 |
| Breaker Type | Standard / H | Standard / H | Standard / H | Standard / H | Standard / H | Standard |
| Rated Ultimate Short-Circuit Breaking Capacity Icu (kA) | AC380/400/415V | 55 / 65 | 65 / 80 | 80 / 85 | 80 / 100 | 100 / 100 | 120 |
| AC660/690V | 25 / 42 | 50 / 65 | 65 / 65 | 65 / 70 | 80 / 75 | 80 |
| Rated Service Short-Circuit Breaking Capacity Ics (kA) | AC380/400/415V | 42 / 65 | 65 / 65 | 65 / 85 | 85 / 80 | 100 / 100 | 100 |
| AC660/690V | 20 / 42 | 40 / 65 | 65 / 65 | 65 / 65 | 75 / 75 | 70 |
| Rated Short-Time Withstand Current Icw/1s (kA) | AC380/400/415V | 42 / 50 | 65 / 65 | 66 / 85 | 85 / 80 | 85 / 85 | 100 |
| AC660/690V | 20 / 42 | 40 / 65 | 55 / 65 | 65 / 65 | 65 / 65 | 70 |
| Number of Poles | 3 / 4 |
| N-Pole Max Continuous Current | 100% In |
| Installation Type | Drawer Type / Fixed Type |
| Electrical Life (operations, maintenance-free) | AC415V | 7000 | 6000 | 5500 | 2000 |
| AC690V | 4500 | 3000 | 1000 |
| Mechanical Life (operations) | With maintenance | 30000 | 20000 | 10000 |
| Maintenance-free | 12000 | 10000 | 6000 |
| Total Breaking Time (no intentional delay) (ms) | ≤30 |
| Closing Time (ms) | ≤70 |
| Arcing Distance (mm) | 0 |
| Connection Type | Horizontal / Vertical |
