| Standard | EN 50155,GB/T 24338.4-2018,EN 45545-2,IEC 61373 |
| Adaption | Acti9 Series 1P-4 |
| Electrical Characteristics | |
| Operating Voltage | 230V AC (70%~125%) 24-48V DC (optional) |
| Control signal | MODBUS-RS485 Wet node 230V high level/pulse signal (optional) |
| Over&under voltage function | 160-270V±5V (Optional) |
| Timing function | Available (optional) |
| Digital display | 3-digit voltage,switching times,fault status |
| Effective control signal duration | ＞400ms |
| Closing action time | ＜1s |
| Opening action time | ＜0.5s |
| Control circuit cable length | ≤1500m |
| Current-carrying capacity of auxiliary contacts(terminals 8-9-10) | 1CO,minimum operating current 3mA(24VDC)(resistive)(optional) |
| Current-carrying capacity of signaling contacts(terminals 5-6-7) | Maximum operating current 2A(30V DC),0.5A(125V AC)(optional) |
| Power consumption | ≤1.5VA（Static）；≤25VA（dynamic） |
| Rated insulation voltage | 400V |
| Rated impulse withstand voltage uimp | |
| (between S2C-RM DC and MCB） | 4kV（4.9kV at sea level） |
| Self-locking protection | Within 10s of 3CO/20s of 4CO/30s of 6CO，the product will self-lock and recover automatically after 40s. |
| Electrical life | 10000 times,3 times/minute |
| Mechanical Characteristics | |
| Indicator Light | Green,Normal status |
| Red,MCB overcurrent fault |
| Auto/Manual switching | Auto Remote control of opening&closing available |
| Manual Remote control of opening&closing disabled |
| Mechanical life | 10000 |
| Protection class | Ip20 |
| Hazard class according to EN 45545-2 | EN 45545-2 R26/HL3 |
| Shock and vibration resistance According to IEC 61373 | category 1-class A/B-body mounted |
| Resistance to heat and humidity IEC/EN 60068-2-30 | 28 cycles（55℃/90-96%，25℃/95-100%） |
| Ambient Temperature | -25..+70℃ |
| Storage Temperature | -40…+70℃ |
| Installation and Wiring | |
| Power and control signal terminal wiring capacity | 28-12AWG 2.5mm² |
| Auxiliary signal terminal wiring capacity | 28-14AWG 1.5mm² |
| DIN rail mounting | DIN rail EN 60715（35mm） |
| Mounting position | Mounting on DIN rail Any position |
