| Parameter | Specification |
| Rated Voltage (Un) | 230/240V |
| Rated Current (In) | 6A, 10A, 16A, 20A, 25A, 32A, 40A |
| Rated insulation voltage (Ui) | 500V |
| Rated impact tolerance voltage (Uimp) | 4kV |
| Rated residual action current (IΔn) | 0.03A, 0.1A, 0.3A |
| Poles | 1P+N |
| Residual current action type | Type A, Type AC |
| Working Frequency | 50/60Hz |
| Rated limit short circuit current (Inc) | 4500A/6000A |
| Rated limit Remaining short circuit current (IΔc) | 4500A/6000A |
| Rated on and off capacity (Im) | 500A |
| Rated residual switching and breaking capacity (IΔm) | 500A |
| Tightening moment | 1.2N·m |
| Class of protection | IP20 |
| Trip Curve | B, C |
