| General description |
| Type of output | NPN NO/NC or PNP NO/NC |
| Detection method | BGS/FGS |
| Rated operating distance Sn | 30cm |
| Standard test substance | White Paper 100 × 100mm |
| Rated level | |
| Rated voltage UB | DC12-24V pulse (P-P) less than 10% (10-30V) |
| Response time | <1ms |
| No-load current Io | <20mA |
| Voltage drop Ud | Below 2VDC (when the load current is less than 100mA) |
| Operating current IL | ≤100mA(With overload protection) |
| Circuit protection | Short circuit protection, power supply reverse polarity protection |
| Switch status indication | Action indication: red LED; Power supply, stability indicator: green LED |
| Surrounding environment | |
| Ambient temperature and humidity | During operation: – 25 ℃~+55 ℃ (non icing)/35~85% RH (non condensation) |
| Ambient temperature and humidity | Storage: – 25 ℃~+70 ℃ (non freezing)/35~95% RH (non dewing) |
| Ambient Lighting | Sunlight: 10000Lx Incandescent lamp: 3000Lx |
| Mechanical properties | |
| Wiring form | PVC conductor leading-out type 2m (standard type) |
| Housing material | ABS |
| Camera lens | Optical PMMA |
| Protection level | IEC specification IP67 |
| High pressure resistance | 1000VAC, 50/60Hz, 1min between the charging unit and the housing |
| Insulation impedance | Above 20MQ (DC500V megger) between the charging unit and the housing |
| Vibration resistance | Durability: 10 ～ 55Hz, complex amplitude 1.5mmX, Y, Z, 2H in each direction |
| Impact resistance | 500m/s2 3 times in X, Y, Z directions |
| Certification and standards | |
| Product certification | CE CCC CQC ISO9001 |
| Compliance with standards | IEC/EN 60947-5-2:2004 |
