| Feature | Specification |
| Frame Type | K1-K4: Molded Enclosure | K5-K12: Metal Unit (compact) |
| Protection | IP20 / UL open type, IP65 / UL |
| Supply Voltage / Power | 1PH AC 200…240V: 0.75 … 15kW (0.5 … 20 hp) 3PH AC 200…240V: 0.75 … 75kW (0.5 … 100 hp) 3PH AC 380…440V: 0.75 … 500kW (0.5 … 660 hp) |
| Motor Control | V/f (V/Hz), Open Loop Vector, Closed Loop control, Direct Torque Control (DTC), EC Motors |
| Max. Frequency | V/f: 0-3000Hz | Vector: 0-500Hz |
| Torque Control | V/f: 0.5Hz/150% | Vector: 0.3Hz/180% |
| Overload Capacity | 120s of 150% rated current, 10s of 180% rated current |
| Input and Output | Digital I/O: 7/1 | Analog I/O: 1/1 | Speed feedback I/O: 1/1 | Relay output: 2 |
| Built-in PLC | Built-in PLC supports up to 16 multi-step speeds. |
| Other Features | NTC / PT100 / PT1000 sensor compatible. Sequence programming available for Constant pressure and temp control, Spindle system. |
| Braking Chopper | Internal braking chopper on 0.75 … 160kW. |
| Communication | Modbus RTU |
| Ambient Temperature | -10°C to 40°C without derating / to 60°C with derating. Humidity up to 90%HR. Optional up to -20°C. |
