| Parameter | Single-Phase (220V) | Three-Phase (380V) |
| Rated Power | 30kVA | 30kVA~500kVA |
| Rated Current | 135A | 45A~750A |
| Rated Voltage | AC220V | AC380V |
| Voltage Range | -40%~+30% |
| Rated Frequency | 50Hz/60Hz |
| Grid Structure | L/N+PE | Three-phase four-wire +PE |
| AC Overload Capability | 1.1 times the duration |
| Output Voltage Accuracy | ±1% |
| Function Selection | Voltage compensation + (reactive power compensation, harmonic compensation, reactive + harmonic compensation) | Voltage compensation + (reactive, harmonic, three-phase unbalance, reactive + harmonic, reactive + unbalance, reactive + unbalance + harmonic compensation) |
| Compensation Voltage Range | AC380 ±20% (-40%~+30% customizable) |
| Transformer Ratio | 5:1 |
| Harmonic Compensation Rate | 3-13th comprehensive harmonic compensation ≥95% |
| Reactive Power Compensation Rate | Reactive power compensation ≥99% |
| Three-Phase Unbalance Compensation Rate | / | Unbalance degree after compensation ≤5% |
| Allowable Grid Frequency | 45~63Hz |
| Output Voltage THD Increment | ≤1% |
| Compensation Response Time | <20ms |
